XSP-6C binocular biological microscope
XSP-6C binocular biological microscope
Product details
Instrument usage:
Batou®XSP-6CThe Type 2 binocular biological microscope is equipped with a large field eyepiece and an achromatic objective lens, with a wide and clear imaging range and strong expandability. It can be applied to research in microbiology, cytology, histology, and other fields. It can also be used as a medical test (non clinical), such as mite detection, skin sectioning, blood analysis, etc. It can be used for various biological experiments in the laboratory and for teaching purposes in universities.
Performance characteristics:
▲ Configure large field eyepiece and achromatic objective lens,Large and clear field of view;
▲ Coarse micro coaxial focusing mechanism,Rough movement with adjustable elasticity,Equipped with locking and limiting devices,Micro grid value:2μm；
▲ 6V 20WHalogen lamp lighting,Adjustable brightness;
Technical Specifications:
|
model |
XSP-6C |
|
eyepiece |
Broad VisionWF10X(Φ18mm) WF16X(Φ11mm) |
|
objective lens |
Achromatic color4X/0.10 |
|
Achromatic color10X/0.25 |
|
|
Achromatic color40X/0.65(spring) |
|
|
Achromatic color100X/1.25(spring,oil) |
|
|
Eyepiece tube |
binoculars(tilt30˚)There is also a three eyed computer model, model number:XSP-8CSeries, can be connected to a computer for imaging. |
|
focusing system |
Coarse micro coaxial focusing,Micro grid value:2Mm,Rough movement with adjustable elasticity,Equipped with locking and limiting devices,Add black plastic hand pillow board on the base |
|
converter |
four holes(Internal positioning of inward ball) |
|
stage |
Double layer mechanical mobile type(size:135mmX125mm,Mobile range: 75mmX35mm) |
|
Abbe spotlight |
N.A.1.25Adjustable up and down |
|
Color filter |
Blue filter |
|
frosted glass |
|
|
Concentrator |
Suitable for halogen lamps |
|
light source |
6V 20W,halogen lamp,adjustable brightness |
Instrument usage:
Batou®XSP-6CThe Type 2 binocular biological microscope is equipped with a large field eyepiece and an achromatic objective lens, with a wide and clear imaging range and strong expandability. It can be applied to research in microbiology, cytology, histology, and other fields. It can also be used as a medical test (non clinical), such as mite detection, skin sectioning, blood analysis, etc. It can be used for various biological experiments in the laboratory and for teaching purposes in universities.
Performance characteristics:
▲ Configure large field eyepiece and achromatic objective lens,Large and clear field of view;
▲ Coarse micro coaxial focusing mechanism,Rough movement with adjustable elasticity,Equipped with locking and limiting devices,Micro grid value:2μm；
▲ 6V 20WHalogen lamp lighting,Adjustable brightness;
Technical Specifications:
|
model |
XSP-6C |
|
eyepiece |
Broad VisionWF10X(Φ18mm) WF16X(Φ11mm) |
|
objective lens |
Achromatic color4X/0.10 |
|
Achromatic color10X/0.25 |
|
|
Achromatic color40X/0.65(spring) |
|
|
Achromatic color100X/1.25(spring,oil) |
|
|
Eyepiece tube |
binoculars(tilt30˚)There is also a three eyed computer model, model number:XSP-8CSeries, can be connected to a computer for imaging. |
|
focusing system |
Coarse micro coaxial focusing,Micro grid value:2Mm,Rough movement with adjustable elasticity,Equipped with locking and limiting devices,Add black plastic hand pillow board on the base |
|
converter |
four holes(Internal positioning of inward ball) |
|
stage |
Double layer mechanical mobile type(size:135mmX125mm,Mobile range: 75mmX35mm) |
|
Abbe spotlight |
N.A.1.25Adjustable up and down |
|
Color filter |
Blue filter |
|
frosted glass |
|
|
Concentrator |
Suitable for halogen lamps |
|
light source |
6V 20W,halogen lamp,adjustable brightness |
