Tracheal suction hoist is a labor-saving equipment that utilizes the principles of vacuum adsorption and vacuum lifting to achieve rapid transportation.

VCL single handed tracheal suction hoist can achieve fast, safe, and labor-saving operation. The highest stack height is 1.8m, and the lifting load is 15kg-65kg;

Vacuum suction crane20kgto40TBoth can be designed and produced according to demand.Committed to Easy Lifting！

1Parameters of the tracheal suction crane for lifting workpieces:

(1)Material: cardboard box，Maximum weight 65kgHorizontal transportation；

(2) Workpiece size: 780 * 400 * 150, etc
(3) Schematic diagram of workpiece displacement: the lowest point A is 150mm above the ground, and the highest point B is 1800mm;

(4)Effective installation height on site:3.2mabove;

(5)Power supply:380VAC±15%, Frequency:50Hz ±1HzThree phase five wire system; Or compressed air at 6 bar, 30m ³/h;

(6)Altitude:200mfollowing.
