Model: YHZD-UV3

1. Studio size: 400mm x 1140mm x 380mm (D x W x H)

2. Dimensions: 500mm × 1300mm × 1460mm (D × W × H)

3. Lamp model: UV-A (315-400nm), UV-B (280-315nm) optional

4. Lamp brand: ATALS imported from the United States

5. Distance of lamp: 60mm

6. Radiation intensity: adjustable within 0.4W/m2 to 1W/m2 (optional)

7. Light temperature range: 50 ℃~70 ℃

8. Condensation temperature range: 40 ℃~60 ℃

9. Light temperature tolerance: ≤± 2 ℃

10. Temperature fluctuation ≤ ± 2 ℃

11. Temperature resolution: 0.1 ℃

12. Blackboard thermometer

13. Measurement range: 30-80 ℃

14. The tolerance is ± 1 ℃

15. Humidity range: 45% to 90% R.H

16. Temperature control method: PID self-tuning temperature control method

17. Water tank requirement: The water depth should not exceed 25mm and there should be an automatic water supply controller

18. Sample rack: 2 sets

19. Standard specimen size: 75 × 90mm (special specification sample holder can be customized)

20. Testing capability: 48 pieces

21. Distance between the test piece and the lamp surface: 50mm

22. The maximum thickness of the sample: 20mm

UV aging experimental machine controller:

Temperature controller: imported LED digital display P, I, D+S, S, R. microcomputer integrated controller

Time Controller: Imported Programmable Time Computer Integrated Controller (YPAD-UV3)

Illumination heating system: fully independent system, nickel chromium alloy electric heating heater

Condensation humidification system: All stainless steel shallow surface evaporative humidifier

Blackboard temperature: bimetallic blackboard thermometer

Water supply system: humidification water supply adopts automatic control

Exposure methods: Moisture condensation exposure, light radiation exposure

The after-sales service reference is as follows:

Aerospace Zhida Technology is striving to improve the quality of its own brand products, reduce failure rates, and provide after-sales service and maintenance. In addition, we constantly solve maintenance problems for other brands and even imported instruments for many customers, because we know that only satisfying customers is the proof of doing a good job.

1. Performance and quality assurance: Strictly design and produce according to the technical specifications of the equipment to ensure that the performance and quality of the equipment meet the requirements agreed upon by both parties. And provide relevant inspection certificates.

2. Transportation and cost issues: Responsible for transporting equipment to the customer's designated location and bearing related costs (excluding stackers, cranes, and movers).

3. Installation, commissioning and acceptance: Free installation and commissioning of equipment until normal operation, and actively cooperate with your company's relevant acceptance work.

4. User operation training: Free training on operation and daily maintenance for your company's equipment users.

5. Problem response and handling: If the equipment encounters problems during use, respond quickly and assign technical engineers to handle and solve the problems in a timely manner. Emergency repairs should be completed within 8 hours, while general repairs should be completed within 24 hours.

6. Free Warranty and Technology: From the date of delivery, the equipment is covered by a one-year free warranty (excluding damage caused by natural disasters, power abnormalities, improper operation and maintenance, self repair or modification). Technical support is free for life.

7. Lifetime maintenance service: For equipment problems that occur during non free warranty periods or do not meet free warranty conditions, we will also provide lifetime maintenance service with a positive attitude, and only charge basic labor, transportation, and spare parts fees. The fees collected will be negotiated with your company in a friendly manner. If there are program issues that cannot be fully confirmed and your company's department head has made a commitment, Aerospace Zhida Technology will prioritize handling equipment issues.
