Name: YK-3151 Load Cabinet

[Product Introduction]：

This load cabinet is designed as a supporting equipment for the breaking capacity and normal operation of electrical accessories. It is used to simulate the electrical life and breaking capacity testing of electrical products under live conditions. Different specifications of load current and surge current can also be customized according to customer requirements. This load cabinet is a cabinet type structure, and the box body is treated with iron plate pressing and spraying. There are four wheels at the bottom of the box for easy movement. The upper front of the box is the control panel, which is made of aluminum plate etching process and sandblasted and colored, durable and long-lasting. There are instrument power switches, intelligent digital voltmeters, ammeters, power meters, power factor meters, power on counters, current output buttons, current stop buttons, alarms, etc. on the panel. Inside the box, there are combinations of inductance and resistance pieces, strong wind cooling mechanisms, voltage regulation systems, high-power reactors, various electrical control components, control circuit boards, and output wiring blocks.

[Technical Specifications]：

※ Load current: 1~20A (or customized according to customer requirements) continuously adjustable, digital display

※ Load voltage: 5~300V continuously adjustable, digital display

※ Power factor: 0.3~0.999 continuously adjustable, digital display

※ Power on/off cycle counter frequency range: 1~999999 can be preset

※ Power supply: AC 220V/50Hz

※ Number of workstations: 3 workstations
