The Leica DMC4500 color camera can capture clear and bright images in daily analysis and recording work. As a comprehensive and easy-to-use tool, the Leica DMC4500 aims to simplify the entire imaging process from capture to processing. Whether it's life science applications such as pathology or drug testing, or industrial applications such as quality control and fault analysis, it's your ideal choice.

The USB 3.0 interface provides a USB 3.0 interface (compatible with USB 2.0 interface) that can be plug and play on any computer or laptop.

Using a mature and reliable 5-megapixel CCD sensor, it runs quickly and efficiently.

Real time imaging speed up to 18 frames per second, allowing for direct sample positioning and focusing on the computer screen.

Experience real-time image preview with SXGA resolution of 1280 x 960 pixels.

Excellent noise suppression capability, perfectly capturing unprocessed CCD signals.

The Leica DMC4500 directly digitizes image information from the CCD chip inside the camera.

◇ Can perform digital conversion with a resolution of 14 bits.

The camera supports true color calibration, providing natural color reproduction effects and generating high-quality images.

In SXGA progressive scanning and full frame mode, real-time images can be quickly captured at frame rates of 18 frames per second and 9 frames per second, respectively.

Leica Application Suite (LAS) and LAS X integrate Leica microscopes, macro mirrors, and digital cameras into a universal environment. With the help of LAS software and LAS X software, you can accelerate the visualization and enhancement of digital images, and measure, record, and archive your images. For specific applications, Leica can also provide expert modules such as Live Image BuilderLive to choose from, making your daily work easier.

(Different Applications of LEICA DMC4500 in Life Sciences and Industrial Fields)

Digital camera Leica DMC4500 Technical Data
Digital camera	Leica DMC4500
Camera type	Digital camera for microscopy with control software
Sensor	interline transfer frame readout CCD – ICX282
Number of pixels	5.0 megapixel, 2560×1920
Cooling	no
Pixel size	3.45 μm x 3.45 μm
Color depth	36Bit
Pixel size	3.4 μm x 3.4 μm
A/D converter	14Bit
Exposure Time	1 msec – 60 sec,step 1usec
Dynamic range	59 dB / > 900:1 dB
Readout noise	4.5LSB9(12bit) typical
Gain control	0-20dB
Region of interest	Freely adjustable in 2 pixels steps from 2 × 2 up to full resolution
Full frame	2560×1920 interlaced (9fps/4.5fps/9fps)
Color binning (2*2)	1280*960 progressive (18fps/9fps)
Subsample	1280*960 progressive (18fps/9fps)
Grayscale	Transferred from color binning(2*2) to mono in software
Data	Single USB3.0(Micro-B connector with screw lock)
Recommended video adapter	C-mount 0.63X(stereo microscoper) or 0.7X(light microscope)
USB USage:USB3.0	USB 3.0 Full functionality of the camera
USB USage:USB2.0	25MHZ clock only,full frame,without binning,subsample or partial scan
Power supply	via USB3.0 cable
Housing	Die cast aluminum
