Dongguan Aerospace Zhida Test Equipment Co., Ltd

It is a powerful tool to enhance your leap into the field of quality. Simulating products involves various environments encountered during manufacturing, assembly, transportation, and use execution stages to assess their ability to withstand environmental vibrations. It is suitable for research, development, quality control, and manufacturing in various industries such as electronics, mechatronics, optoelectronics, automobiles, and toys. It is a rare testing machine for you to improve the reliability of product quality.

function Sine wave, amplitude modulation, fixed frequency sine wave,amplitude modulation,programmable,frequency sweep,frequency doubling,time control, four hundred and eighty-fiveCommunication interface,logarithm

Test loadKG 100 100 100 100 100 100 100 100

frequency range0.01Hzpower frequency1-600(1Sto1Year's time) 1-5000(1Sto1Year's time)

Sweep frequency range0.01Hznone1-600(1Sto30Time of the day) 1-5000(1Sto30Time of the day)

amplitude 0—5mm

acceleration20g

direction of vibration vertical level vertical level vertical+level vertical level vertical+level

Vibration waveform sine wave

Programmable（0.01Hz） none none1-600(15segment/65500Srecyclable) 1-5000(15segment/65500Srecyclable)

Frequency doubling（0.01Hz） none none1-600(15segment/65500Srecyclable) 1-5000(15segment/65500Srecyclable)

485Communication interface none none Can be connected to a computer for control area, storage, recording, and printing functions (computer control isOPTION）

time control Can be set at any time(In seconds)

Vibration machine power（KW）2.2KW 3.8KW

Workbench dimensions(L*W) 50cm*50cm{Maximum（3*3）}

power supply voltage(V) 220V 380V

current(A) 10

Platform size(CM) 50*20*50 50*25*20 50*20*50 50*25*50Two countertops50*20*50 50*25 *50Two countertops

Note:1g=9.8m/S2acceleration=0.002*f2*D(unitg) f=frequency(unitHz)
