Product Description: How to Translate
Fast speed and stable performance have won the trust of users with their superior performance and quality. Wide range of applicable materials, capable of marking the vast majority of non-metallic materials. The device can control the depth of engraving by adjusting the power output of the laser. It can not only print the surface of the processed material, but also deeply engrave and cut the product, greatly enriching the processing performance of the product. The software has a powerful automatic coding function, which can mark serial numbers, dates, times, barcodes, etc. It can also be used in conjunction with an automatic anti-counterfeiting and anti counterfeiting system, and the number of printing lines is not limited. Widely used in industries such as food, beverage, tobacco, electronics, handicrafts, plastics, etc., it is suitable for the production characteristics of modern assembly lines. Marking trademarks, models, etc. on ceramic capacitors and ICs, with clear, beautiful, and never worn printing, has strong anti-counterfeiting effect. Cooperate with automated feeding systems to achieve a comprehensive solution for processing bulk and bagged parts. Packaging for food, medicine, beverages, etc; It is widely used in industries such as PCB board, electrical equipment, sheet metal, wire, electronic components, etc.

2、 Main configuration
Small in size and easy to install, Leadjet C-series laser coding machine has a novel appearance design, small in size, and light in weight. It can be equipped with a small workbench or mounting bracket to match the production line according to actual needs. More environmentally friendly, energy-efficient non-contact processing, more environmentally friendly, and pollution-free. The whole machine has low power, fast marking speed, low operating cost, and no post production expenses. Easy to use, strong compatibility. Controlled by a computer, simple to operate, easy to use, strong anti-interference ability, massive storage space, multi-directional input and output interfaces, can be used in conjunction with automatic anti-counterfeiting and anti string systems.

3、 Main technical parameters
Model: Leadjet C-30B Leadjet C-10B
Laser: CO2 RF laser
Laser power: 30W/10W (optional)
Cooling method: air-cooled
Wavelength: 9.3um/10.6um (optional)
Line width: 0.02mm
Depth: 0.4mm (depending on the material)
Industrial grade controller: Industrial control computer
Printing content: text, logo, barcode, QR code, graphics, images, dot matrix; Built in multiple laser engraved fonts, fully automatic serial number can achieve ultra long printing without being limited by the marking format
Scope of work: 100 × 100mm (70 × 70mm, 145 × 145mm, 175 × 175mm optional). Mark content freely within the scope of work, without being limited by the number of lines
Information input: keyboard input USB、 Serial data communication and other information input
Interface: Ethernet USB、RS232、 Multi channel definition l/O
Pipeline speed: 0-150 meters per minute
Protection: The host's optical path is fully enclosed and not affected by dust
Environmental requirements: Temperature: 5-40 ℃, humidity ≤ 95%, no condensation
Power supply requirement: AC220V/50Hz
Power: 800W
