CFL2604 (260 horsepower four-wheel drive)
Basic configuration: Yuchai A08 six cylinder engine, air-conditioned cab, 32+32 crawling gear, single acting clutch, electronic control power output,
Product details
Basic configuration: Yuchai A08 six cylinder engine, air-conditioned cab, 32+32 crawling gear, single acting clutch, electronic control power output, 8- φ 48-540/1000, front radial tires 540/65R30, rear radial tires 650/65R42, electronic control hoist, electronic control differential lock, electronic control four-wheel drive, hydraulic power assisted braking, hydraulic power assisted clutch, adjustable towing device, swing traction, four sets of hydraulic outputs, front counterweight 20 pieces of 1000 kg, LCD instrument panel, 360 surround view system, multi condition power adjustment, satellite positioning, film sticking.
Powerful and efficient economy
Equipped with standard Yuchai engine and Bosch high-pressure common rail, it has low fuel consumption, fast acceleration, strong power, durability and reliability, and will not lose speed under heavy loads.
It has a multi working condition mode selection function, with three levels: fuel-efficient, standard, and explosive. Users can choose the corresponding mode reasonably according to the working conditions to effectively save fuel.
Equipped with premium clutch, high reliability and longer lifespan.
Turning radius of 6.5 meters, flexible turning, suitable for large and small plots of land.
Standard 32+32 speed gearbox with crawl gear. Optional 64+32 speed gearbox, including power high and low gears and power reversing.
Reasonable homework speed, high homework efficiency, and low fuel consumption. In heavy load areas such as Xinjiang and Heilongjiang, the plowing efficiency of the 550 hydraulic flipping plow reached 30.8 acres per hour, with a fuel consumption of only 1.80 liters per acre.
The high road speed (38.68 kilometers per hour) provides advantages for field transfer and transportation operations.
460L large capacity fuel tank, meeting the requirements for long-term continuous operation.
Easy to operate and free to control
Standard synchronizer shift, optional power shift and power shuttle, making shifting easier.
Hydraulic power assisted main clutch and hydraulic power assisted brake control provide more comfortable operation.
Electronic control power output, electronic control four-wheel drive, electronic control differential lock, one click control is lightweight and comfortable.
Comfortable and luxurious driving experience
Car soft package interior, fully adjustable seats, full LCD instrument panel, intelligent integrated display screen, infinitely adjustable steering wheel, car turn signal controller, fully wrapped elastic floor mat, high brightness work lights.
A large amount of double impedance sound insulation materials are used, with a distance of 2 meters from a 130 decibel sound source and only 73.2 decibels inside the cab.
Dry powder spraying does not introduce dust, with good dust prevention effect; 20 minutes of rain without leakage, with good waterproof effect. Surrounding air outlet provides better air conditioning cooling effect.
The manipulation is arranged within the optimal range of both hands, in accordance with ergonomics. Equipped with mobile phone charging interface, USB interface, tea cup holder, cigarette lighter, storage box, etc., in line with humanized design.
Superior performance, safe and reliable
Heavy duty front axle with high reliability.
Equipped with imported electronic control elevator system as standard, the lifting force can reach over 52kN, which can automatically adjust the force and position according to the field soil and unit operation conditions in a timely and accurate manner.
The hydraulic cylinder adjustment of the upper pull rod and lifting rod can quickly level the implement.
Changfa specially designed reinforced suspension has significantly increased strength, robust appearance, reliable quality, and long service life.
The fast hanging device enables single person operation to hang agricultural machinery, which is economical and efficient.
Equipped with imported hydraulic valves, premium gear pumps, and quick change couplings, it has high reliability and longer lifespan.
Brand new design, streamlined design of hood, roof, and mudguard, with a strong overall visual impact.
The hood is lower in front and higher in the back, with narrower sides, providing a wider field of view.
Raise the mudguard to create a larger gap between the tire and mudguard without clogging.
The brightness of the front LED headlights is 35000 Candela. The all-round and panoramic work light provides a wide field of view for night work, and the dynamic streamlined turn signal is fashionable and trendy.
Satellite positioning system
Real time positioning: GPS/Beidou system uploads the location of agricultural machinery in real time, providing accurate services to users.
Driving trajectory: Real time recording of the historical trajectory of agricultural machinery driving, assisting users in calculating the operating area.
Fault diagnosis: Remote monitoring of the operation status of agricultural machinery, providing convenient guidance and problem-solving for farmers.
Maintenance reminder: Intelligent push of vehicle maintenance information to enhance user experience.
Homework statistics: Real time collection of homework data to assist users in understanding the status of agricultural machinery operations.
